CJZD-600 Fully automatic Hi-speed Three side sealed &zipper bag/pouch making machine
Product Description:
The Three Side Sealing & Zipper Machine is a high-quality packaging machine designed for various types of products. It is perfect for sealing and packaging granular, powder, liquid, and solid materials in a three-side sealed bag or pouch. This machine is a must-have for any company or business that requires efficient and reliable packaging solutions.
The Three Side Sealing & Zipper Machine is suitable for a wide range of products, making it a versatile and valuable investment. It can be used for packaging snacks, such as chips, nuts, and candies, with the option of adding a zipper for easy opening and resealing. It is also perfect for packaging masks, ensuring they are sealed and protected from external elements.
This machine is designed for high efficiency and productivity. It is easy to operate, with simple controls and adjustments for different bag sizes and materials. The three-side sealing method ensures a tight and secure seal, keeping the products fresh and intact. The zipper feature also allows for convenient storage and transportation of the packaged products.
The Three Side Sealing & Zipper Machine is made with top-quality materials and advanced technology, ensuring durability and long-term use. It is also designed with safety features to prevent accidents and ensure the well-being of the operators.
Specifications:
| Suitable material | Suitable for various heat sealing composit films |
| Tube size | Max width:1000mm,max diameter:Ф800mm |
| Film thickness | 0.045-0.15mm(single layer) |
| Bag making speed | three side sealing: 250 segments/min, Three side zippered bag: 200 segments/min |
| Bag making width | 75-500mm |
| Bag making length | 440mm(longitudinal sealing twice) |
| Control system | PLC control system |
| Material traction mechanism | Servo motor system traction |
| Discharge system | Discharge shaft,tripod or K frame |
| Braking device | Constant tension encoder magnetic particle control system |
| Overall power | 40kw |
| Cooling water | About 15L/min |
| Air supply | 0.6Mpa |
| Power supply | Three phase 380V/50HZ |
| Weight | Apx5000kgs |
| Dimension | 13×2.×2.2m(L×W×H) |
Applications:
Three-side sealing with zipper bag has good barrier performance, moisture resistance, low heat sealing and high transparency, suitable for three-sided sealed bag products such as tea, candy, powder bag, snack food, nuts and seeds, rice, makeup bag, mask eye mask bag, medicine bag etc.with zipper function it has Strong sealing, moisture-proof, air-tight and UV proof.
